DS18 ENS-PRO1.5KP212LD PANCADAO Ported box with 2 X 12" Mid-Bass PRO-1.5KP12.2 Loaded
Designed for the enthusiast who wants to shake the room, DS18’s ENS-PRO1.5KP212LD delivers an unparalleled listening experience that transports you to another dimension. DS18’s ENS-PRO1.5KP212LD combines one of DS18’s mid-bass loudspeakers with a perfectly tuned ported box for a listening experience like no other.
At the heart of this enclosure are two of DS18’s PRO-1.5KP12.2, DS18’s booming mid-bass loudspeakers engineered to redefine your sound system’s boundaries. Equipped with a massive 4” voice coil, and constructed from fiber glass for unparalleled stability, the PRO-1.5KP12.2 was built for those who like it LOUD!
Chosen for it’s rigid construction and unreal responsiveness, DS18’s pursuit of perfection in audio led them to the creation of a custom-designed ported box specifically tailored to complement the PRO-1.5KP12.2. Every inch of this front-ported box constructed from premium ¾” MDF, is engineered to maximize this mid-bass loudspeaker’s potential.
DS18’s ENS-PRO1.5KP212LD flawlessly reproduces mid bass frequencies that highlight the depth and richness of your favorite tracks. The ENS-PRO1.5KP212LD's technical prowess is further enhanced by its sensitivity of 96dB and an impressive frequency response ranging from 50Hz to 2KHz. The 3.52ft3 internal volume of the ENS-PRO1.5KP212LD gives this speaker enough room to perform at it’s best. With a total RMS power handling of 3000W and a maximum power handling of 6000W, prepare to be blown away by the sheer intensity and clarity of your music.
Indulge your senses, elevate your audio experience, and let DS18’s ENS-PRO1.5KP212LD transport you to a world where sound knows no boundaries.
Highlights
- RMS power handling of 3000W and a MAX power handling of 6000W
- 6" (H) x 38.6" (W) x 15.75" (D)
- 52ft3 front-ported box is constructed from premium 3/4" MDF for optimal resonance control, resulting in tight mid bass reproduction
Great For
- Car Audio
- Pro Audio
Technical Details
GENERAL | |
Speaker Type / Size | Dual 12" / 304mm |
Total Impedance | 1 ohm |
Total RMS Power Handling | 3000 W |
Total MAX Power Handling | 6000 W |
Sensitivity (1w/1m) | 97dB |
Frequency Response | 50Hz-2KHz |
Recommended HI Pass Crossover | 60 HZ |
MIDRANGE SPECIFICATIONS | |
Model | PRO-1.5KP12.2 |
Voice Coil Diameter | 4" / 101.6mm |
Voice Coil Former Material | Fiber Glass |
Winding Material | CCAW |
Cone Material | Non-Pressed Paper |
Dust Cap Material | Paper |
Surround Material | Cloth |
Basket Material | Aluminum |
Magnet Material | Ferrite |
Magnet Weight | 150 oz |
BOX SPECIFICATIONS | |
Internal Volume | 2 x 50L / 1.76ft3 |
Port Tune | 75Hz |
Box Type | Front Ported |
Box Material | 3/4" / 19mm MDF |
Finish Material | Black Carpet |
-3Db Dropping Point | 65Hz |
MEASUREMENT | |
Overall Height | 19.6" / 500mm |
Overall Width | 38.6" / 980mm |
Overall Depth | 15.75" / 400mm |
Port Dimensions (W/H/L Each) | 4.72"x12.8"x9.4" / 120x325x238mm |
